Description
Why Lumin U1 MINI
With LUMIN M1, Lumin’s aim was clear take all the award-winning sonic characteristics that the LUMIN music players are renowned for and surprise people with just how amazing an integrated system can sound.
18 months of continual development lead to Lumin’s uniquely efficient design including an oversized switching power supply and a fully-digital signal path all the way to the speaker outputs.
Features
The same LUMIN musical delivery, with integrated amplification
Compact system
Class-D power amplification retains digital signal path right to the speaker outputs
60W @ 8 Ohm Speaker / 100W @ 4 Ohm Speaker
Oversized switching power supply
Includes DSD128 5.6Mhz 1-bit playback
PCM 44.1384kHz 1632-bit
Analogue input via included adapter
Volume controlled by physical knob, or in-app
All the usual Lumin refinements
From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs
The unique and intuitive LUMIN App described as “the most convenient interface in existence” by Tinman
LUMIN programme of continuous development that has seen Roon, MQA, and Spotify support added in 2017 alone.
The reviews speak for themselves
Since its launch, LUMIN M1 has gathered amazing reviews from around the globe.
Technical Specifications
DSD SUPPORT
Up to DSD128 5.6MHz, 1-bit
PCM SUPPORT
Up to 384kHz, 1632-bit, Stereo
PHYSICAL OUTPUT
Stereo 4 mm banana binding posts
SPEAKER LOAD
4 Ohm
RATED POWER OUTPUT (PER CHANNEL)
60W into 8 Ohm Speaker
100W into 4 Ohm Speaker
INPUT
Analogue RCA stereo and mini-jack input via included USB adapter
POWER SUPPLY
Oversized 100240V AC auto-ranging
FINISH
Raw brushed aluminium
DIMENSIONS
361mm (W), 323mm (D), 58mm (H), 4.5kg
Specifications for all Lumin Music Streamers
STREAMING PROTOCOL
UPnP AV protocol with audio streaming extension (OpenHome)
Roon Ready
Spotify Connect
AirPlay-compatible
Gapless Playback
On-Device Playlist
APP FEATURES
Native support for TIDAL, MQA, Qobuz and TuneIn Radio.
Tidal MQA icons to identify high-res music
Qobuz high-res icons to identify high-res music
Volume control
High-resolution artwork
Artwork caching
Search
Multiple tag handling
Composer tag support
Album-grouping in playlist
Automatic internet links to artists/album/songs
Saving and restoring of playlists (including Tidal and Qobuz)
SUPPORTED AUDIO FILE FORMATS
DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
Compressed (lossy) Audio: MP3, AAC (in M4A container) MQA
INPUT
Ethernet RJ45 network 100Base-T
USB storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)
ANALOGUE AUDIO OUTPUTS
XLR balanced, 4Vrms, pin 2 Hot
RCA unbalanced, 2Vrms
SUPPORTED CONTROL DEVICES
All models of Apple iPad (v2 or later). iOS 8.0 or later required. Full Retina Display support.
Android devices. Android 4.0 (Ice Cream Sandwich) or later required
OTHER
Leedh Processing lossless digital volume control
Programme of Continuous Development Firmware-upgradable for further features and enhancements
Manufacturer site
- Lumin
